Ubiquiti UISP Router UISP-R UISP-R

Mechanical





Dimensions

210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14")





Weight

600 g (1.32 lb)





Enclosure material

Polycarbonate





Hardware





Networking interface

(8) 10/1001000 MbE RJ45 ports

(1) 1G SFP port





Management interface

Ethernet in-band

Bluetooth BLE





Processor

Dual-core 880 MHz, MIPS1004Kc





Memory

512 MB DDR3





Onboard flash storage

512 MB NAND





Power method

External AC/DC adapter





Power supply

27VDC, 4.4A power adapter (included)





Supported voltage range

24 - 28VDC





Max. power consumption

10W (excludes PoE output)





ESD/EMP protection

Air: ± 15 kV, contact: ± 8 kV





Operating temperature

-10 to 50° C (14 to 122° F)





Operating humidity

5 to 95% non-condensing





Certifications

CE, FCC, IC





PoE





PoE interface

(8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-)





Max. Passive PoE wattage per port

30W/27VDC





Passive PoE voltage range

27VDC





LEDs





System

Status





RJ45 data ports

PoE

Speed/link/activity





SFP data port

Link/activity
