Ubiquiti UniFi Redundant WAN PRO over LTE U-LTE-PRO U-LTE-PRO

Mechanical





Dimensions

66 x 202 x 32 mm (2.60 x 7.96 x 1.27"")





Weight

Without stand: 223 g (7.86 oz)

With stand: 336 g (11.85 oz)





Enclosure material

Polycarbonate





Mount materials

Stand: aluminum

Wall mount: polycarbonate









Hardware





Processor

74 Kc MIPS Processor at 775 MHz





Memory information

128 MB DDR2





Management interface

Ethernet





Networking interface

(2) 10/100/1000 MbE RJ45 ports

WP7607 LTE





SIM

Nano-SIM





LTE bands

CAT4, B1/3/7/8/20/28





LCM display

1.54" screen





Power method

PoE+, Passive PoE (48V)





Power Supply

UniFi PoE switch

48V, 0.5A PoE adapter





Supported voltage range

44—57V DC





Max. power consumption

8.5W





Max. TX power

19 dBm





MIMO

U-LTE 2 x 2 Category 4 LTE radio





Throughput speeds

150 Mbps





Antenna gain

LTE

B1

B3

B7

B8

B20

B28





2 dBi

1.5 dBi

2 dBi

3.5 dBi

2 dBi

2 dBi





Button

Factory reset





Mounting

Wall mount, foot stand (included)





ESD/EMP protection

Air/Contact: ± 24 kV





Operating temperature

-10 to 60° C (-14 to 140° F)





Operating humidity

5 to 95% noncondensing





Certifications

CE, FCC, IC
