STARTECH 4 PORT VGA USB KVM SWITCH
A kép csak illusztráció!
The SV431USB 4 Port rack mountable VGA USB KVM Switch with Hub offers simple control of up to four computers from a single monitor/display and USB peripheral set (keyboard, mouse).
The USB KVM switch features an integrated 4 port USB hub, allowing you to share connected USB peripherals between the four controlled PC/Mac computers as though the devices were connected directly.
Offering convenient placement and installation options, the KVM switch features a 1U rack-mountable form factor and rear port connection to master and slave computers, allowing you to make the necessary device connections without disrupting your workspace.
A cross-platform solution, the KVM switch supports high resolution applications at up to 1920x1440 and provides a smooth operating experience when controlling mixed (Windows/Mac OS/Linux) environments.
Backed by a StarTech.com 3 year warranty and free lifetime technical support.
Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
Hardware
Audio
No
Cables Included
No
Daisy-Chain
No
KVM Ports
4
Multi-Monitor
No
PC Interface
USB
PC Video Type
VGA
Rack-Mountable
Optional
U Height
1U
Performance
Auto Scan
3, 8, 15 & 30 seconds
DVI Support
No
Hot-Key Selection
No
IP Control
No
Maximum Analog Resolutions
1920 x 1440
Maximum Cable Length
16.4 ft [5 m]
Maximum Number of Users
1
MTBF
82,506 Hours
Port Selection Support
Push Button
Connector(s)
Console Interface(s)
1 - VGA (15 pin; High Density D-Sub) Female
4 - USB A (4 pin) Female
Host Connectors
4 - USB B (4 pin) Female
4 - VGA (15 pin; High Density D-Sub) Male
Software
OS Compatibility
OS independent; No software or drivers required
Special Notes / Requirements
Note
In order to use the SV431USB with a USB keyboard that has additional USB ports, such as an Apple Macintosh keyboard, or to use the SV431USB with a USB hub, an additional power supply may be required
Power
Center Tip Polarity
Positive
Input Current
0.4A
Input Voltage
110 ~ 240 AC
Output Current
2A
Output Voltage
5 DC
Plug Type
N
Power Source
Not Included (not required for standard applications)
Physical Characteristics
Color
Black
Enclosure Type
Steel
Product Height
1.7 in [44 mm]
Product Length
8.7 in [220 mm]
Product Weight
31.8 oz [900 g]
Product Width
5.1 in [130 mm]
Packaging Information
Shipping (Package) Weight
3 lb [1.3 kg]
What's in the Box
Included in Package
1 - 4 Port VGA USB KVM Switch
4 - Rubber Feet
1 - Instruction Manual
The USB KVM switch features an integrated 4 port USB hub, allowing you to share connected USB peripherals between the four controlled PC/Mac computers as though the devices were connected directly.
Offering convenient placement and installation options, the KVM switch features a 1U rack-mountable form factor and rear port connection to master and slave computers, allowing you to make the necessary device connections without disrupting your workspace.
A cross-platform solution, the KVM switch supports high resolution applications at up to 1920x1440 and provides a smooth operating experience when controlling mixed (Windows/Mac OS/Linux) environments.
Backed by a StarTech.com 3 year warranty and free lifetime technical support.
Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
Hardware
Audio
No
Cables Included
No
Daisy-Chain
No
KVM Ports
4
Multi-Monitor
No
PC Interface
USB
PC Video Type
VGA
Rack-Mountable
Optional
U Height
1U
Performance
Auto Scan
3, 8, 15 & 30 seconds
DVI Support
No
Hot-Key Selection
No
IP Control
No
Maximum Analog Resolutions
1920 x 1440
Maximum Cable Length
16.4 ft [5 m]
Maximum Number of Users
1
MTBF
82,506 Hours
Port Selection Support
Push Button
Connector(s)
Console Interface(s)
1 - VGA (15 pin; High Density D-Sub) Female
4 - USB A (4 pin) Female
Host Connectors
4 - USB B (4 pin) Female
4 - VGA (15 pin; High Density D-Sub) Male
Software
OS Compatibility
OS independent; No software or drivers required
Special Notes / Requirements
Note
In order to use the SV431USB with a USB keyboard that has additional USB ports, such as an Apple Macintosh keyboard, or to use the SV431USB with a USB hub, an additional power supply may be required
Power
Center Tip Polarity
Positive
Input Current
0.4A
Input Voltage
110 ~ 240 AC
Output Current
2A
Output Voltage
5 DC
Plug Type
N
Power Source
Not Included (not required for standard applications)
Physical Characteristics
Color
Black
Enclosure Type
Steel
Product Height
1.7 in [44 mm]
Product Length
8.7 in [220 mm]
Product Weight
31.8 oz [900 g]
Product Width
5.1 in [130 mm]
Packaging Information
Shipping (Package) Weight
3 lb [1.3 kg]
What's in the Box
Included in Package
1 - 4 Port VGA USB KVM Switch
4 - Rubber Feet
1 - Instruction Manual
