STARTECH 4 PORT USB KVM SWITCH

The SV431DUSBU 4 Port 1U Rack Mountable USB KVM Switch with OSD lets you control multiple USB based computers from a single console (USB keyboard, USB mouse, monitor).

Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options.

Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet (with optional mounting bracket SV431RACK) and offers rear cable connections to eliminate cable tangles and minimize workspace disruption.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

Rackmount your KVM switch

If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.









Hardware





Audio

No





Cables Included

No





Daisy-Chain

Yes





KVM Ports

4





Multi-Monitor

No





PC Interface

USB





PC Video Type

VGA





Rack-Mountable

Optional





Performance





DVI Support

No





Hot-Key Selection

Yes





IP Control

No





Maximum Analog Resolutions

1920 x 1440@60Hz (1920 x 1200@60Hz - Wide Screen)





Maximum Number of Users

1





Port Selection Support

Push Button, Hotkeys, and OSD (On Screen Display)





Wide Screen Supported

Yes





Connector(s)





Console Interface(s)

1 - VGA (15 pin; High Density D-Sub) Female







2 - USB A (4 pin) Female





Host Connectors

4 - VGA (15 pin; High Density D-Sub) Female





Software





OS Compatibility

OS independent; No software or drivers required





Indicators





LED Indicators

1 - Green - Power







4 - Green - Online PC







4 - Red - Selected PC





Power





Center Tip Polarity

Positive





Input Current

0.2A





Input Voltage

110 ~ 240 AC





Output Current

0.6A





Output Voltage

9 DC





Plug Type

M





Power Source

AC Adapter Included





Environmental





Humidity

80% RH





Operating Temperature

5°C to 40°C (41°F to 104°F)





Storage Temperature

-20°C to 60°C (-4°F to 140°F)





Physical Characteristics





Color

Black





Enclosure Type

Steel





Product Depth

5.1 in [130 mm]





Product Height

1.7 in [43 mm]





Product Weight

52.9 oz [1500 g]





Product Width

8.7 in [220 mm]





Packaging Information





Shipping (Package) Weight

3.6 lb [1.6 kg]





What's in the Box





Included in Package

1 - 4-port KVM switch







4 - foot pads







1 - universal power adapter (NA/EU/UK/AU)







1 - instruction manual
