STARTECH 4 PORT DUAL DVI USB KVM SWITCH

The SV431DD2DUA 4-port Dual DVI USB KVM Switch allows up to four PCs, each with dual DVI video outputs, to share two monitors, one microphone and set of speakers, one keyboard and one mouse as well as two other USB peripherals.

An ideal solution for graphic designers, CAD/CAM designers or educational and financial institutions, the dual view KVM Switch allows you to instantly switch back and forth between dual DVI display PCs at the touch of a button, while maintaining professional level video quality on both monitors. The dual DVI switch also features an integrated USB hub port that allows USB 2.0 peripherals such as thumb drives, external hard drives or web cams to be shared between attached systems - eliminating duplicate peripheral costs.

Please Note: While both DVI-I (analog mode) and DVI-D (digital only) are supported by the KVM, both source PCs should output the same signal type for proper switching. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to Console connections. Please contact technical support if you require assistance identifying your source.

Backed by a StarTech.com 3 year warranty and free lifetime technical support.



The StarTech.com Advantage



Integrated USB 2.0 hub and Mic/Audio ports allow the user to have full multimedia control of two computers and share USB peripherals eliminating the expense of duplicate devices

Take full advantage of Dual head video cards by switching up to four machines across two high resolution DVI monitors

Absolutely no software or drivers required providing a completely OS independent KVM solution









Hardware





Audio

Yes





Cables Included

No





Daisy-Chain

No





KVM Ports

4





Multi-Monitor

Yes





PC Interface

USB





PC Video Type

DVI





Rack-Mountable

Optional





Performance





DVI Support

Yes - Single Link





Hot-Key Selection

Yes





IP Control

No





Maximum Analog Resolutions

2048x1536 @85Hz





Maximum Digital Resolutions

1920x1200 @60Hz





Maximum Number of Users

1





Port Selection Support

Push Button and Hotkeys





Connector(s)





Console Interface(s)

2 - 3.5 mm Mini-Jack (3 Position) Female







2 - DVI-I (29 pin) Female







4 - USB A (4 pin) Female





Host Connectors

4 - USB B (4 pin) Female







8 - 3.5 mm Mini-Jack (3 Position) Female







8 - DVI-I (29 pin) Female





Software





OS Compatibility

OS independent; No software or drivers required





Indicators





LED Indicators

1 - Green - Power







4 - Green - Host Online, Red - Host Selected





Power





Center Tip Polarity

Positive





Input Current

0.8A





Input Voltage

110 ~ 240 AC





Output Current

1.5A





Output Voltage

12 DC





Plug Type

M





Power Source

AC Adapter Included





Environmental





Humidity

90% RH





Operating Temperature

0°C to 40°C (32°F to 104°F)





Storage Temperature

-20°C to 60°C (-4°F to 140°F)





Physical Characteristics





Color

Black





Enclosure Type

Steel





Product Depth

5.1 in [130 mm]





Product Height

2.4 in [60 mm]





Product Weight

44.2 oz [1253 g]





Product Width

8.7 in [220 mm]





Packaging Information





Shipping (Package) Weight

4 lb [1.8 kg]





What's in the Box





Included in Package

1 - 4 Port Dual DVI USB KVM







4 - Rubber Feet







1 - Universal Power Adapter (US/EU/UK) and AU in Australia







1 - Instruction Manual
