STARTECH FIBER MEDIA CONVERTER - OPEN MCM1110SFP

This fiber media converter offers an easy, cost-effective way to extend your network over fiber, using the SFP of your choice. It converts a copper RJ45 Ethernet connection to Gigabit fiber to extend your network over longer distances or connect workstations to switches. The converter provides a powerful networking solution for campuses, businesses, government facilities, stadiums, or other areas requiring network access.

A cost-effective extension and flexible performance

The Gigabit fiber media converter provides a cost-efficient way to connect your Ethernet network to remote devices over a fiber backbone. It features an open SFP slot that lets you choose the MSA-compliant Gigabit SFP that best suits your fiber connection mode (single / multimode) and distance requirements.

A versatile way to connect different networks

Fully compatible with 10/100/1000Base-T Ethernet networks, the fiber media converter supports auto negotiation to bridge different speed networks and devices to a Gigabit fiber network. It provides versatile connectivity to your existing networks and devices, allowing you to maximize the usage and performance of legacy equipment.

Installation is fast and easy

The unmanaged fiber media converter has a standalone design with simple plug-and-play set-up to ensure fast and easy installation. Compact in size, the converter gives you flexible installation options - including a wall mounting option.

The MCM1110SFP is backed by a StarTech.com 2-year warranty and free lifetime technical support.









Hardware





Industry Standards

IEEE 802.3 10BASE-T







IEEE 802.3u 100BASE-TX







IEEE 802.3ab 1000BASE-T







IEEE 802.3z 1000BASE-SX







IEEE 802.3z 1000BASE-LX





PoE

No





WDM

No





Performance





Auto MDIX

Yes





Compatible Networks

10/100/1000 Mbps





Fiber Operating Mode

Full-Duplex





Fiber Type

Multi Mode







Single Mode





Maximum Data Transfer Rate

1 Gbps





MTBF

> 50,000 hours at 25°C





Connector(s)





Local Unit Connectors

1 - RJ-45 Female







1 - SFP Slot Female





Special Notes / Requirements





Note

Fiber data transfer speeds and distances are dependent on the SFP transceiver used (sold separately)





Indicators





LED Indicators

1 - Power







1 - Fiber Port Link/Act







1 - Copper Port Link/Act







1 - 1000 Mbps





Power





Center Tip Polarity

Positive





Input Current

1 A





Input Voltage

100 ~ 240 AC





Output Current

2 A





Output Voltage

5 DC





Plug Type

N





Power Consumption

5 W Max





Power Source

AC Adapter Included





Environmental





Humidity

5~95% RH (Non-condensing)





Operating Temperature

0°C to 50°C (32°F to 122°F)





Storage Temperature

-10°C to 70°C (14°F to 158°F)





Physical Characteristics





Color

Brown





Enclosure Type

Steel





Product Height

1 in [26 mm]





Product Length

3.7 in [95 mm]





Product Weight

6.5 oz [185 g]





Product Width

2.8 in [70 mm]





Packaging Information





Shipping (Package) Weight

17.3 oz [489 g]





What's in the Box





Included in Package

1 - Gigabit Ethernet fiber media converter w/ open SFP slot







1 - universal power adapter (NA/EU/UK/AU)
