STARTECH FIBER ETHERNET MEDIA CONVERTER MCM110SC2EU

The MCM110SC2EU 10/100 Multi Mode Fiber Ethernet Media Converter (SC, 2 km) creates a cost-effective Ethernet-fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals, to extend an Ethernet network connection over an SC-terminated multimode fiber backbone.

The converter supports a maximum multimode fiber optic cable distance of 2 kilometers (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using SC-terminated multimode fiber, while delivering solid network performance and scalability.

This versatile GbE Ethernet to Fiber converter is compatible with most 3COM™, Cisco™, Lucent™ and Nortel™ networks and fully complies with applicable IEEE 802.3 standards.









Hardware





Industry Standards

IEEE 802.3 10BASE-T







IEEE 802.3u 100BASE-FX







IEEE 802.3u 100BASE-TX





PoE

No





WDM

No





Performance





Fiber Operating Mode

Half/Full-Duplex





Fiber Type

Multi Mode





Max Transfer Distance

2 km (1.2 mi)





Maximum Data Transfer Rate

10/100Mbps





MTBF

65,000 Hours





Wavelength

1310nm





Connector(s)





Local Unit Connectors

1 - RJ-45 Female





Remote Unit Connectors

1 - Fiber Optic SC Duplex Female





Indicators





LED Indicators

1 - Ethernet Link & Activity (ON - Fiber Link ok, Blinking - Activity on Fiber Link)







1 - FEF [Far End Fault](On - Fault Detected, Off - No Fault







1 - Fiber Link & Activity (On - Fiber Link ok, Blinking - Activity on Fiber Link)







1 - Full ( Full duplex / Half duplex)







1 - Power







1 - Speed (10 or 100 Mbps)





Power





Center Tip Polarity

Positive





Input Voltage

230 AC





Output Current

0.2A





Output Voltage

12 DC





Plug Type

M





Power Source

AC Adapter Included





Environmental





Humidity

10~90% RH





Operating Temperature

0°C to 50°C (32°F to 122°F)





Storage Temperature

-10°C to 70°C (14°F to 158°F)





Physical Characteristics





Color

Black





Product Height

20 mm [0.8 in]





Product Length

95 mm [3.7 in]





Product Weight

90.5 g [3.2 oz]





Product Width

75 mm [3 in]





Packaging Information





Shipping (Package) Weight

0.3 kg [0.6 lb]





What's in the Box





Included in Package

1 - Media Converter







1 - EU power plug







1 - UK power plug







1 - Power Adapter







1 - User's Manual
