QNAP QGD-1600P-4G QNAP QGD-1600P-4G, 4C Intel, 16x1GbE with 2xRJ45 and SFP+, 2x2,5 SATA, QGD-1600P-4G

Management Type

Web Managed





CPU

Intel® Celeron® J4115 quad-core 1.8 GHz processor (burst up to 2.5 GHz)





CPU Architecture

64-bit x86





System Memory

4 GB (1 x 4 GB)





Drive Bays

2 x 2.5-inch SATA 6Gb/s, 3Gb/s





Number of Ports

16





1GbE (RJ45)

14





1GbE SFP/RJ45 Combo Ports

2





Total PoE Ports

16





PoE PSE (802.3af, 15.4W)

Ports 1-16





PoE+ PSE (802.3at, 30W)

Ports 1-16





PoE++ PSE (802.3bt, 60W)

Ports 1-4





PoE Power Output

Ports 1-4 (60W), Ports 5-16 (30W)





Total PoE Power Budget

360W





PCIe Slot

Slot 1: PCIe Gen2 (x2)

Slot 2: PCIe Gen2 (x2)





USB 3.2 Gen 1 port

1





USB 2.0 port

2





Management Port

1 x 1GbE





USB 3.2 Gen 2 (10Gbps) Port

Optional via PCIe adapter





HDMI Output

1





Power Supply Description

Internal Power Supply Unit





Max. Power Consumption

418W





Input Power Type

AC





Input Voltage Range

100-240VAC, 50/60 Hz





MAC Address Table

8K





Total Non-Blocking Throughput

16Gbps





Switching Capacity

32Gbps





Management Interface

Web





Energy Efficient Ethernet (IEEE 802.3az complaint)

Yes





Fan

System: 2 x 4 cm (12V DC)





Supported Standards

IEEE 802.3u 100Tx Fast Ethernet

IEEE 802.3ab 1000BASE-T Gigabit Ethernet

IEEE 802.3z 1000Base-X

IEEE 802.3x Full-duplex flow control

IEEE 802.3af/at/bt Power-over-Ethernet (PoE)

IEEE 802.1q Virtual LANs (VLAN)

IEEE 802.1p QoS Protocol for Traffic Prioritization





Form Factor

Rackmount





LED Indicators

Per Port: Link/Activity/Speed/PoE

Per System: Warning/PoE/Fan





LCD Management

Yes





Buttons

Device PSU power button

Host power button

Host reset button(load default)

Switch reset button





Dimensions (HxWxD)

47,2 × 436,2 × 326,2 mm





Weight (Net)

4.41 kg





Weight (Gross)

5.56 kg





Operating Temperature

0°C to 40°C (32°F to 104°F)





Relative Humidity

5% to 95% non-condensing, wet bulb: 27°C (80.6°F)





Certifications

CE, FCC, VCCI, BSMI RCM, CCC





Electromagnetic Compliance

CLASS A, UL62368





Jumbo Frames

9k





QTS Built-in

Yes





Internal Network Bandwidth

2 x 1GbE





Graphics Processors

Intel® HD Graphics 600





Floating Point Unit

Yes





Encryption Engine

 (AES-NI)





Maximum Memory

8 GB





Memory Slot

2 x SODIMM DDR4





Flash Memory

4GB (Dual boot OS protection)





Drive Compatibility

2.5-inch bays:

2.5-inch solid-state drives

2.5-inch hard disk drives





Hot-swappable

Yes





M.2 SSD Slots

Optional via PCIe adapter





SSD Cache Acceleration Support

Yes





File System: Internal Hard Drive

EXT4





File System: External Hard Drive

EXT3, EXT4, NTFS, FAT32, HFS+, exFAT (optional license)
